Aged Care

Email Brochure to a friend Download pdf brochure


Internal Applications Aged Care \| NCC Class 9c View Wall Types:						NCC / OTHER REQUIREMENTS
						FRL	ACOUSTIC
						COLUMNS AND WALLS	STAIR, LIFT, DUCT, LOBBY OR CORRIDOR WALL	PLANT, UTILITIES, BATHROOM OR SANITARY COMPARTMENT WALL		KITCHEN OR LAUNDRY WALL		LOAD BEARING PARTITION WALL	SOLE-OCCUPANCY DIVIDING WALL
				SYSTEM PERFORMANCE		All internal load bearing walls and columns	All (including those that separate a sole-occupancy unit)	Not separating a sole-occupancy unit	Separating a sole-occupancy unit	Not separating a sole-occupancy unit	Separating a sole-occupancy unit	Separating rooms within a sole-occupancy unit	Separating sole- occupancy units from each other
System Components	Dincel Profile	Min. Plaster board Thick-ness	Total Wall Width	Rw (Rw+Ctr)	Maximum FRL achievable	Up to 120/120/120² FRL	No acoustic req.	No acoustic req.	Meets acoustic req. (Rw ≥ 45)	No acoustic req.	Meets acoustic req. (Rw ≥ 45 and 2 or more separate leaves)	No acoustic req.	Meets acoustic req. (Rw ≥ 45)
DIN-IW1 Dincel Wall left bare left bare	110	N/A	110	48 (43)	90/90/90¹	-	✔	✔	✔	✔	-	✔	✔
	155	N/A	155	51 (45)	180/180/180¹	✔	✔	✔	✔	✔	-	✔	✔
	200	N/A	200	53 (48)	240/240/240¹	✔	✔	✔	✔	✔	-	✔	✔
	275	N/A	275	53 (48)	240/240/240¹	✔	✔	✔	✔	✔	-	✔	✔
DIN-IW2 Dincel Wall plasterboard left bare	110	10	120	45 (41)	90/90/90¹	-	✔	✔	✔	✔	-	✔	✔
	155	13	168	50 (45)	180/180/180¹	✔	✔	✔	✔	✔	-	✔	✔
	200	10	210	51 (46)	240/240/240¹	✔	✔	✔	✔	✔	-	✔	✔
	275	10	285	51 (46)	240/240/240¹	✔	✔	✔	✔	✔	-	✔	✔
DIN-IW3 Dincel Wall plasterboard plasterboard	110	10	130	45 (41)	90/90/90¹	-	✔	✔	✔	✔	-	✔	✔
	155	13	181	50 (45)	180/180/180¹	✔	✔	✔	✔	✔	-	✔	✔
	200	10	220	51 (46)	240/240/240¹	✔	✔	✔	✔	✔	-	✔	✔
	275	10	295	51 (46)	240/240/240¹	✔	✔	✔	✔	✔	-	✔	✔
DIN-IW4 Dincel Wall plasterboard 28mm furring channels (600 c/c, 30mm cavity), plasterboard	110	13	166	45 (42)	90/90/90¹	-	✔	✔	✔	✔	-	✔	✔
	155	10	205	48 (43)	180/180/180¹	✔	✔	✔	✔	✔	-	✔	✔
	200	10	250	53 (46)	240/240/240¹	✔	✔	✔	✔	✔	-	✔	✔
	275	10	325	53 (46)	240/240/240¹	✔	✔	✔	✔	✔	-	✔	✔
DIN-IW5 Dincel Wall plasterboard 28mm furring channels (600 c/c, 30mm cavity), 25mm glasswool (HD), plasterboard	110	10	160	53 (46)	90/90/90¹	-	✔	✔	✔	✔	-	✔	✔
	155	10	205	55 (48)	180/180/180¹	✔	✔	✔	✔	✔	-	✔	✔
	200	10	250	57 (50)	240/240/240¹	✔	✔	✔	✔	✔	-	✔	✔
	275	10	325	57 (50)	240/240/240¹	✔	✔	✔	✔	✔	-	✔	✔
DIN-IW6 Dincel Wall 28mm furring channels (600 c/c, 45mm cavity), 25mm glasswool (HD), plasterboard 28mm furring channels (600 c/c, 45mm cavity), 25mm glasswool (HD), plasterboard	110	16	232	63 (50)	90/90/90¹	-	✔	✔	✔	✔	-	✔	✔
	155	13	271	60 (52)	180/180/180¹	✔	✔	✔	✔	✔	-	✔	✔
	200	13	316	63 (54)	240/240/240¹	✔	✔	✔	✔	✔	-	✔	✔
	275	13	391	63 (54)	240/240/240¹	✔	✔	✔	✔	✔	-	✔	✔
DIN-IW7 Dincel Wall left bare 51mm steel studs (600 c/c, 71mm cavity), plasterboard	110	10	191	51 (43)	90/90/90¹	-	✔	✔	✔	✔	✔	✔	✔
	155	10	236	54 (45)	180/180/180¹	✔	✔	✔	✔	✔	✔	✔	✔
	200	10	281	57 (47)	240/240/240¹	✔	✔	✔	✔	✔	✔	✔	✔
	275	10	356	57 (47)	240/240/240¹	✔	✔	✔	✔	✔	✔	✔	✔
DIN-IW8 Dincel Wall plasterboard 51mm steel studs (600 c/c, 71mm cavity), 50mm glasswool (LD), plasterboard	110	13	207	57 (50)	90/90/90¹	-	✔	✔	✔	✔	✔	✔	✔
	155	13	252	63 (51)	180/180/180¹	✔	✔	✔	✔	✔	✔	✔	✔
	200	10	291	61 (53)	240/240/240¹	✔	✔	✔	✔	✔	✔	✔	✔
	275	10	366	61 (53)	240/240/240¹	✔	✔	✔	✔	✔	✔	✔	✔
DIN-IW9 Dincel Wall 28mm furring channel (600 c/c, 30mm cavity), plasterboard 51mm steel studs (600 c/c, 71mm cavity), plasterboard	110	10	231	47 (41)	90/90/90¹	-	✔	✔	✔	✔	✔	✔	✔
	155	10	276	51 (43)	180/180/180¹	✔	✔	✔	✔	✔	✔	✔	✔
	200	10	321	55 (46)	240/240/240¹	✔	✔	✔	✔	✔	✔	✔	✔
	275	10	396	55 (46)	240/240/240¹	✔	✔	✔	✔	✔	✔	✔	✔
DIN-IW10 Dincel Wall 28mm furring channel (600 c/c, 30mm cavity), plasterboard 51mm steel studs (600 c/c, 71mm cavity), 50mm glasswool (LD), plasterboard	110	13	237	57 (50)	90/90/90¹	-	✔	✔	✔	✔	✔	✔	✔
	155	13	282	63 (51)	180/180/180¹	✔	✔	✔	✔	✔	✔	✔	✔
	200	13	327	61 (53)	240/240/240¹	✔	✔	✔	✔	✔	✔	✔	✔
	275	13	402	61 (53)	240/240/240¹	✔	✔	✔	✔	✔	✔	✔	✔
DIN-IW11 Dincel Wall 28mm furring channel (600 c/c, 30mm cavity), 25mm glasswool (HD), plasterboard 51mm steel studs (600 c/c, 71mm cavity), 50mm glasswool (LD), plasterboard	110	HD13	237	62 (50)	90/90/90¹	-	✔	✔	✔	✔	✔	✔	✔
	155	HD13	282	67 (52)	180/180/180¹	✔	✔	✔	✔	✔	✔	✔	✔
	200	HD13	327	68 (53)	240/240/240¹	✔	✔	✔	✔	✔	✔	✔	✔
	275	HD13	402	68 (53)	240/240/240¹	✔	✔	✔	✔	✔	✔	✔	✔

Download the Internal and External data tables


External Applications View Wall Types:				NCC / OTHER REQUIREMENTS
				FRL		WATERPROOFING
				COLUMNS AND WALLS		BASEMENT WALL		FAÇADE, BALUSTRADE OR BLADE WALL		TANK WALL	RETAINING OR PLANTER BOX WALL
			SYSTEM PERFORMANCE	Type A & B construction (those that require FRL)	Type C construction (those that require FRL)	Above the water table	Underneath the water table	Separating exterior environment from interior	Exterior environment on both sides of the wall	All	All
System Components	Dincel Profile	Total Wall Width	Maximum FRL achievable	Up to 120/120/120² FRL	Up to 90/90/90² FRL	Waterproof	Submerged conditions	Waterproof (and includes insulation)	Waterproof	Waterproof	Waterproof
DIN-EW1 Dincel Wall left bare left bare	110	110	90/90/90¹	-	✔	✔	.-³		✔	✔	✔
	155	155	180/180/180¹	✔	✔	✔	.-³		✔	✔	✔
	200	200	240/240/240¹	✔	✔	✔	.-³		✔	✔	✔
	275	275	240/240/240¹	✔	✔	✔	✔³		✔	✔	✔
DIN-EW2 Dincel Wall choice of finish: paint, render or cladding left bare	110	110	90/90/90¹	-	✔	✔	.-³		✔	✔	✔
	155	155	180/180/180¹	✔	✔	✔	.-³		✔	✔	✔
	200	200	240/240/240¹	✔	✔	✔	.-³		✔	✔	✔
	275	275	240/240/240¹	✔	✔	✔	✔³		✔	✔	✔
DIN-EW3 Dincel Wall left bare 50mm+ cavity, secondary wall for habitable room (either 110 Dincel, lightweight partition, masonry or dry wall)	110	283	90/90/90¹	-	✔	✔	.-³			✔	✔
	155	328	180/180/180¹	✔	✔	✔	.-³			✔	✔
	200	373	240/240/240¹	✔	✔	✔	.-³			✔	✔
	275	448	240/240/240¹	✔	✔	✔	✔³			✔	✔
DIN-EW4 Dincel Wall choice of finish: paint, render or cladding 40mm insulation board, 28mm furring channel on clips, 13mm plasterboard	110	191	90/90/90¹	-	✔			✔
	155	236	180/180/180¹	✔	✔			✔
	200	281	240/240/240¹	✔	✔			✔
	275	356	240/240/240¹	✔	✔			✔
DIN-EW5 Dincel Wall 110mm brick veneer w/20mm cavity 40mm insulation board, 28mm furring channel on clips, 13mm plasterboard	110	321	90/90/90¹	-	✔			✔
	155	366	180/180/180¹	✔	✔			✔
	200	411	240/240/240¹	✔	✔			✔
	275	486	240/240/240¹	✔	✔			✔
DIN-EW6 Dincel Wall Insulated panel system on top hats 28mm furring channels on clips, 13mm plasterboard	110	268	90/90/90¹	-	✔			✔
	155	313	180/180/180¹	✔	✔			✔
	200	358	240/240/240¹	✔	✔			✔
	275	433	240/240/240¹	✔	✔			✔

The ‘NCC/Other requirements’ information provided above is for guidance purposes only please check with your consultants for specific requirements for your project.

The above requirements are based upon the NCC deemed-to-satisfy provisions (Specification C1.1 and F5.0 - F5.5)

The above performance is based on the following product densities:

10mm thick plasterboard - 650 kg/m³ bulk density
13mm thick plasterboard - 623 kg/m³ bulk density
HD13mm thick plasterboard (HD = High Density, typically fire rated plasterboard) - 808 kg/m³ bulk density
16mm thick plasterboard - 766 kg/m³ bulk density
25mm thick glasswool insulation (HD) - 24 kg/m³ bulk density
50mm thick glasswool insulation (LD) - 11 kg/m³ bulk density
Concrete within Dincel formwork - 2350 kg/m³ bulk density

¹Dependant on design and wall loading. 'Structural Adequacy' component of FRL must be calculated and provided by the project's structural engineer, in accordance to AS3600, Eurocode or other relevant concrete design codes.

²FRL requirement is based upon a wall with a distance of less than 1.5m from a fire source feature. Please check the NCC for other FRL requirements which may be applicable to your project.

³Dincel recommends the 275 profile for permanently submerged applications due to enhanced design. For more information please refer to waterproofing documentation on our website.
